PCB Punching Machine With FPC Punching Tool

Brand Name : Winsamrt

Model Number : SMTP300

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD1-10000/set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets

Delivery Time : 7-15 days

Packaging Details : Plywood case

After-sale Service : 24H Online Support

PCB Thickness : 0.4-3.5mm

Test Report : Provide

Video Training : Yes

Precision : ±0.05mm

Name : PCB Punching Machine

Contact Now

PCBA Die Tooling PCB Punching Machine PCB / FPC Punching Tool

Our Advantages:

Our machine is completed with fine finishing in accordance with the quality standards of the industry.
Our strict quality management system maintains the excellent performance and quality of our products.
The product is the preferred one in the fields for its huge economic benefits.

Features:

Double switch start operation.

Device configuration mode and out of the chute,and out of the lower mold automatic pick and place convenient and safe products.

Emergency stop switch,identify problems and timely shutdown.

Security doors,installation and commissioning of the mold to avoid straying hands.(Normal operation with out security door doesnot work).

Safety pressure setting function,limit alarm.Automatic counting,limit down time.

The internal stress generated when the cutting board to a minimum and to avoid cracking of tin.

Suitable for high volume routed boards.

Specification:

Working area 460*320mm　
Working pressure 0.45-0.7Mpa
Cutting precision ±0.05mm
Cycle time 7-15 seconds
Output 8T
PCB/FPC thickness 0.08-3.5MM
PCB/FPC material FPC, FR1, FR4, CEM-1, CEM-3, MCPCB
Cutting mode Punching
Punch fixture Die tooling(mold)
Working Property

LCD display, Automatically records the number of

processed products, automatic punching
Transmission port International standard
Operation Language English
Stroke 50MM
Mold height 170MM
Power 380/220V
Fuse 3A
Machine dimension 820x740x1750mm
Machine weight 580kgs

Details:

PCB Punching Machine With FPC Punching ToolPCB Punching Machine With FPC Punching ToolPCB Punching Machine With FPC Punching Tool

Shipment:

1. DHL/FedEx/UPS/TNT Express

2. Air

3. Railway

4. Ocean

5. Truck
